test:C63000 Bronze Solid Round Bar 1-3/4" Diameter

C63000 Bronze Solid Round Bar 1-3/4" Diameter

C63000 Bronze Solid Round Bar 1-3/4" Diameter

Question? We are here to HELP!

For tips and advice on the best products for your project, call us at 1.800.875.3558.

  • ITEM OVERVIEW

    C63000 Nickel Aluminum Bronze is an extruded aluminum bronze that contains nickel, and is alloyed for exceptional strength and toughness. It's used where higher mechanical properties are required. It's used in equipment for the energy markets, in aircraft, marine and a host of other industrial applications. It finds use as valve stems, high strength bushings, valve guides and seats, gears, cams, ship propellers, as well as propeller nuts and shafts

    Machinability - 30

    Chemical Composition:

    Cu - Remainder

    Sn - 0.20%

    Zn - 0.30%

    Fe - 2.00 - 4.00%

    N i- 4.00 -5.50%

    Al - 9.00 - 11.00%

    Mn - 0.00 - 1.50%

    Si - 0.25%

    Other Specifications:

    AMS 4640

    ASTM B150

    ASKERSOLUTIONS 10000317419

    BAKER BMS K099

    EXPRO MS-1142/MS1195

    FMC M40300

    GE MS004

    HALLIBURTON D00001024

    PATHFINDER 070.84727

    SLB 101015538 / 100891990

    SLB SH217036 / SH217037

  • TOLERANCES

    DRAWN TO SIZE OD TOLERANCE +/-0.004

C63000 Bronze Solid Round Bar 1-3/4" Diameter

C630 | Nickel Aluminum Bronze | AMS 4640
$12.92
Total Price:
$12.92

How to order multiple pieces

  1. Enter the length of the material above.
  2. Click "Add to Cart".
  3. Enter your total quantity of pieces on the next page (the cost price per piece is lower when ordering more than one of a specific size)
  4. Continue shopping or proceed to checkout

Warning this product may contain chemicals known by the state of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.p65warnings.ca.gov

how to measure Diameter text will be added here.

How to measure length text will be added here.

how to measure Thickness text will be added here.

how to measure Width text will be added here.

How to measure Inside Diameter text will be added here.

How to measure Outside Diameter text will be added here.

Shipping Restrictions

UPS does a great job shipping our packages at a reasonable price but they have specific limitations when it comes to the maximum size of a package that they will ship.  If your item is over 106” long and/or over 150 lbs it can’t go UPS.  Don’t worry you still have a couple of options.  Many times our customers do not need the full length of the bar they order and have us cut it in half in order to ship via UPS.  To have this done, simply enter “cut in  ½ for shipping” in the “special instructions” box on this page.

If a shorter piece won’t work for you give us a call and we can work it out for you.  We ship via most of the major LTL carriers

Shipping Options

UPS does a great job shipping our packages at a reasonable price, but they have specific limitations when it comes to the maximum size of a package that they will accept..  If your item is longer than 72” long and/or over 150 lbs it cannot ship via UPS.

Don’t worry, you can do one of two things:

MATERIAL THAT CAN BE CUT INTO SHORTER LENGTHS

If your selected material is over 72 inches in length and/or over 150 lbs in weight, but will eventually be cut into smaller pieces, select your material again, but this time using shorter lengths and multiple pieces. Problem solved, it will ship UPS.

MATERIAL THAT CANNOT BE CUT INTO SHORTER PIECES

If your selected material exceeds 72 inches in length and/or 150 lbs in weight and cannot be cut into smaller pieces, no problem, just call us toll free at 888-567-5044 (8:30 am – 5 pm EST), we’ll arrange the shipping for you.
