CHEMICAL COMPOSITION:
(%max., unless shown as range or min.)
NOTE: Information courtesy of Copper.org
Cu(1) | Al | Sb | Fe | Pb | Ni(2) | P(3) | Si | S | Sn | Zn | |
Min./Max. | 84.0-86.0 | .005 | .25 | .30 | 4.0-6.0 | 1.0 | .05 | .005 | .08 | 4.0-6.0 | 4.0-6.0 |
Nominal | 85.0 | - | - | - | 5.0 | - | - | - | - | 5.0 | 5.0 |
MECHANICAL PROPERTIES:
(measured at room temperature, 68 F (20 C)
NOTE: Information courtesy of Copper.org
Temper | Section Size |
Cold Work |
Typ/ Min |
Temp | Tensile Strength |
Yield Strength (0.5% ext. under load) |
El | Rockwell Hardness |
Brinell Hard. |
Fatigue Strength* |
|||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
in. | % | F | ksi | ksi | % | B | C | F | 30T | 500 | 3000 | ksi | |||||||
mm. | C | MPa | MPa | MPa | |||||||||||||||
As Sand Cast | |||||||||||||||||||
M01 | 0.0 | 0 | TYP | 68 | 37 | 17 | 30 | - | - | - | - | 60 | - | 11 | |||||
0.0 | 20 | 255 | 117 | 30 | - | - | - | - | 60 | - | 76 | ||||||||
As Centrifugal Cast | |||||||||||||||||||
M02 | 0.0 | 0 | SMIN | 68 | 30 | 14 | 20 | - | - | - | - | - | - | - | |||||
0.0 | 20 | 207 | 97 | 20 | - | - | - | - | - | - | - | ||||||||
As Continuous Cast | |||||||||||||||||||
M07 | 0.0 | 0 | SMIN | 68 | 36 | 19 | 15 | - | - | - | - | - | - | - | |||||
0.0 | 20 | 248 | 131 | 15 | - | - | - | - | - | - | - | ||||||||
As Sand Cast | |||||||||||||||||||
M01 | 0.0 | 0 | SMIN | 68 | 30 | 14 | 20 | - | - | - | - | - | - | - | |||||
0.0 | 20 | 205 | 97 | 20 | - | - | - | - | - | - | - |
APPLICABLE SPECIFICATIONS:
NOTE: Information courtesy of Copper.org
Product | Specification |
Centrifugal | AMS 4855 ASTM B271 SAE J462, J461 |
Continuous | ASTM B505 SAE J462, J461 |
Fittings | ASME B16.15, SB62, B16.32, B16.26, B16.23, B16.18 ASTM B62 FEDERAL WW-P-460 |
Flanges | ASME SB62, B16.24 ASTM B62 |
Ingot | ASTM B30 |
Precision | MILITARY MIL-C-11866 |
Sand | AMS 4855 ASME SB62 ASTM B584, B62 SAE J461, J462 |
Unions | FEDERAL WW-U-516 |
